WyreStorm NHD-128-NDI-TRX 4K30 NDI to AV over IP Gateway
WyreStorm NHD-128-NDI-TRX 4K30 NDI to AV over IP Gateway - Görsel 2
,

WyreStorm NHD-128-NDI-TRX 4K30 NDI to AV over IP Gateway

Teklif Al

WyreStorm NHD-128-NDI-TRX bridges NDI and NetworkHD with bidirectional 4K30 conversion, PoE, and cloud management. Ideal for lecture halls, courtrooms, and corporate AV.

Stok kodu: NHD-128-NDI-TRX Kategoriler: ,

WyreStorm NHD-128-NDI-TRX bridges NDI and NetworkHD with bidirectional 4K30 conversion, PoE, and cloud management. Ideal for lecture halls, courtrooms, and corporate AV.

Marka

WyreStorm
Model

NHD-128-NDI-TRX
Video Input Port

LAN: 1 x RJ-45 Female Connector
Video Input Type

NHD: H.264/H.265, RTP/UDP, Multicast NDI: NDI HX (NDI 6), RUDP/TCP, Multicast
Input Resolutions

NHD: Up to 4K@30Hz NDI Main stream: Up to 4K@30Hz Preview Stream: Up to 480P@60Hz
Input Bitrate

NHD: Up to 16Mpbs NDI Main stream: Up to 16Mpbs Preview Stream: Up to 1Mbps
Video Output

LAN: 1 x RJ-45 Female Connector
Video Output Type

NHD: H.264/H.265, RTP/UDP, Multicast NDI Main stream: NDI HX (NDI 6), RUDP/TCP, Multicast Preview Stream: MJPEG, HTTP
Output Resolutions

NHD: Up to 4K@30Hz NDI Main stream: Up to 4K@30Hz Preview Stream: CIF (360 x 240) @30Hz
Output Encoding Rate

NHD: Up to 16Mpbs NDI Main stream: Up to 20Mpbs Preview Stream: Up to 512Kbps
Control Method

Front panel LED screen Rear panel RESET button LAN-based control (Web UI, Telnet API, and NHD-CTL-PRO controller)
Power

20V DC 1A, PoE
ESD Protection

Human body model: ±12kV (air-gap discharge) / ±8kV (contact discharge)
