The NHD-150-RX is an enhanced MultiView display decoder compatible with the NetworkHD 120 Series, an ultra-low bandwidth AV over IP solution for distribution of point-to-point, one-to-many and many-to-many over a managed network. The NHD-150-RX decoder is intended for use with 120 Series encoders (sold separately) to provide a complete end-to-end video distribution system. When used in conjunction with the NHD-CTL-PRO system controller complete control integration is simple.
Low Bandwidth AV over IP (1G), NetworkHD AV over IP
WyreStorm NHD-150-RX — NetworkHD 100 Series 4K60 4:2:0 MultiView Processor
The NHD-150-RX is an enhanced MultiView display decoder compatible with the NetworkHD 120 Series, an ultra-low bandwidth AV over IP solution for distribution of point-to-point, one-to-many and many-to-many over a managed network. The NHD-150-RX decoder is intended for use with 120 Series encoders (sold separately) to provide a complete end-to-end video distribution system. When used in conjunction
| Marka | WyreStorm |
|---|---|
| Model | NHD-150-RX |
| Inputs | 1x 1GbE 8-Pin RJ45 |
| Outputs | 1x HDMI Out 1x 3-pin Terminal Block (3.5mm) |
| End to End Latency | 1080p: High Quality Mode: ~250ms Low Latency Mode: ~80ms 4K: High Quality Mode: ~300ms Low Latency Mode: ~150ms |
| Audio Formats | LPCM/MPEG4 AAC stereo, 48KHz |
| Video Resolution (Max) | 3840x2160p @ 60Hz 1920x1080p @ 60Hz |
| Maximum Pixel Clock | 297MHz |
| HDMI | HDMI 1.4, HDCP 2.2, EDID, CEC |
| RS-232 | 1x 3-Pin Phoenix (API control) |
| LAN | 1x 8-pin RJ-45 female, 10/100/1000Base-T, PoE 802.1af |
| Security Protocols | AES 128, SSH, HTTPS |
| Power Supply | 12V DC 1A, 802.3af PoE Compliant |
| Max Power Consumption | 3.6W (DC adapter) |
