WyreStorm NHD-120-TX is a 4K30 AV over IP encoder with H.264/H.265 compression, PoE, and video wall support. Ideal for classrooms, offices, retail, and digital signage.
Low Bandwidth AV over IP (1G), NetworkHD AV over IP
WyreStorm NHD-120-TX 4K AV over IP Encoder with H.264/H.265
WyreStorm NHD-120-TX is a 4K30 AV over IP encoder with H.264/H.265 compression, PoE, and video wall support. Ideal for classrooms, offices, retail, and digital signage.
| Marka | WyreStorm |
|---|---|
| Model | NHD-120-TX |
| Inputs | TX: 1 x HDMI 19-pin HDMI type A RX: 1x 8-pin RJ-45 female |
| Outputs | TX: 1x 3-pin Phoenix Analog Audio (de-embed from HDMI input) RX: 1x HDMI 19-pin HDMI type A 1x 3-pin Phoenix Analog Audio Both HDMI and Analog outputs allow discrete audio routing from any available NHD-120-TX on the same network. |
| End to End Latency | 1080p: High Quality Mode: ~250ms Low Latency Mode: ~80ms 4K: High Quality Mode: ~300ms Low Latency Mode: ~150ms |
| Audio Formats | LPCM/MPEG4 AAC stereo, 48KHz |
| Video Resolution (Max) | 1920x1080p @ 60Hz 3840x2160p @ 30Hz 4:2:0 8bit |
| Maximum Pixel Clock | 297MHz |
| HDMI | HDMI 1.4, HDCP 2.2, EDID, CEC |
| RS-232 | 1x 3-Pin Phoenix – API controlled from CTL |
| LAN | 1x 8-pin RJ-45 female, 10/100/1000 Base-T, PoE 802.1af |
| IR | 1x IR TX: 3.5mm TS Jack Socket 1x IR RX: 3.5mm TS Jack Socket IR signals can be bi-directional passthrough or via API commands from NHD-CTL-PRO for routable IR to discrete TX/RX devices |
| Security Protocols | AES 128, SSH, HTTPS |
| Power Supply | 12V DC 1A, 802.3af PoE Compliant |
| Max Power Consumption | 3.6W (DC adapter) |
| Video Encoding | H.264/H.265 |
