WyreStorm NHD-500-IW-TX v2 — NetworkHD 500 Series 4K60 4:4:4 JPEG2000 In-Wall Encoder
WyreStorm NHD-500-IW-TX v2 — NetworkHD 500 Series 4K60 4:4:4 JPEG2000 In-Wall Encoder - Görsel 2
,

WyreStorm NHD-500-IW-TX v2 — NetworkHD 500 Series 4K60 4:4:4 JPEG2000 In-Wall Encoder

Teklif Al

The NHD-500-IW-TX v2 brings versatility to your AV over IP applications. This 2-gang in-wall 500 series encoder features HDMI and USB-C switching inputs suited for connecting today’s modern laptops and tablets. Perfect for education or corporate environments, install this encoder in a wall, table, desk, podium or anywhere a remote input is needed. Integrated USB extension allows laptops to also co

Stok kodu: NHD-500-IW-TX v2 Kategoriler: ,

The NHD-500-IW-TX v2 brings versatility to your AV over IP applications. This 2-gang in-wall 500 series encoder features HDMI and USB-C switching inputs suited for connecting today’s modern laptops and tablets. Perfect for education or corporate environments, install this encoder in a wall, table, desk, podium or anywhere a remote input is needed. Integrated USB extension allows laptops to also connect to peripheral components such as conference cameras, smartboards/touchscreens and more.

Marka

WyreStorm
Model

NHD-500-IW-TX v2
Inputs/Outputs

1x HDMI In 1x USB-C In 1x 3.5mm TRS Analog In
Output Video Encoding

JPEG 2000
Encoding Data Rate

Max: 850Mbps (configurable)
End to End Latency

4ms video latency @4K60 (pass-through mode), 1-2 video frames latency (scaler/VW mode)
Video Resolution (Max)

5120x2160p@50/60Hz 4:2:0 CVT 5120x1440p@50/60Hz 4:2:0 CVT 4096x2160p @ 60Hz 8bit 4:4:4 or RGB 3840x2160p @ 60Hz 12bit 4:2:2 Dolby Vision 3840x 2160p @ 60Hz 10bit 4:2:2 HDR10/HLG 1920x1080p @60Hz 12bit
Supported Standards

RGB, DCI, USB 1.1, 2.0, BT.2020
Maximum Pixel Clock

600MHz
HDMI

HDMI 2.0b, HDCP 2.3, EDID
RS-232

1x 3.5mm, 2-way, API Programmable
Network

1x 1GbE RJ45
USB

1x USB-C Host (Up to 200Mbps upstream)
Security Protocols

AES 256, SSH, HTTPS
Power Supply

20V DC 6A, 802.3af PoE Compliant
Max Power Consumption

Max 15.4, Average: 8w
