The MX-0808-SCL is a sophisticated HDMI matrix switcher designed for fast Seamless switching. Perfectly suited for professional environments such as corporate training rooms, hotel meeting spaces, and academic classrooms, this device boasts an integrated 4K60 scaler on each HDMI output, scaling from 480p to 2160p. Additionally, it features a comprehensive USB-C input . delivering support for 4K60 video, a 1GbE passthrough network connection, and PD3.0 USB host charging up to 60 watts, ensuring compatibility and ease of use across a variety of devices and setups.
Discontinued Products, Matrix Solution
WyreStorm MX-0808-SCL — 4K60 8×8 Seamless Scaling HDMI Matrix with USB-C Support
The MX-0808-SCL is a sophisticated HDMI matrix switcher designed for fast Seamless switching. Perfectly suited for professional environments such as corporate training rooms, hotel meeting spaces, and academic classrooms, this device boasts an integrated 4K60 scaler on each HDMI output, scaling from 480p to 2160p. Additionally, it features a comprehensive USB-C input . delivering support for 4K60
| Marka | WyreStorm |
|---|---|
| Model | MX-0808-SCL |
| Inputs | 1 x USB-C Input 7 x HDMI Inputs |
| Outputs | 8 x HDMI Outputs 4 x 4 Pin |
| Video Encoding | Uncompressed 18Gbps |
| Audio Formats | 2ch PCM, Multichannel: LPCM and Up to DTS-X and Dolby Atmos |
| Video Resolution (Max) | 1920x1080p @60Hz 16bit 7m/23ft 3840x2160p @60Hz 10bit 4:2:2 HDR10/10+ 5m/16ft 3840x2160p @60Hz 12bit 4:2:0 Dolby Vision 5m/16ft 3840x2160p @50Hz 10bit 4:2:2 HLG 5m/16ft 4096x2160p @60Hz 8bit 4:4:4 5m/16f |
| Supported Standards | DCI, RGB, HDR10, HDR10+, Dolby Vision, HLG, BT.2021 |
| Max Pixel Clock | 600MHz |
| HDMI | HDMI 2.0, HDCP 2.2/2.3, EDID, CEC |
| RS-232 | 1x 3-pin Phoenix |
| LAN | 1x 8-pin RJ-45 for API control (Telnet, TLS, HTTP/HTTPS for webUI) |
| Reset | Via API, WebUI or Pin-Hole reset button |
| Power Supply | AC Power Supply 100V-240V |
| MAX Power Consumption | TBD |
| Dimensions | 19 Inch x 1RU |
| Weight | TBD |
