Discover the WyreStorm EX-70-H2C 4K HDMI extender kit. Extend uncompressed 4K@60Hz 4:4:4 HDMI signals up to 70m over Cat6/6a/7 with HDMI loop out, ARC. Ideal for home theaters, meeting rooms, and professional AV installs.
HDMI Extender
WyreStorm EX-70-H2C 70m 4K HDMI Extender over Cat6 with ARC
Discover the WyreStorm EX-70-H2C 4K HDMI extender kit. Extend uncompressed 4K@60Hz 4:4:4 HDMI signals up to 70m over Cat6/6a/7 with HDMI loop out, ARC. Ideal for home theaters, meeting rooms, and professional AV installs.
| Marka | WyreStorm |
|---|---|
| Model | EX-70-H2C |
| Input/Output Signal Type | HDMI 2.0, HDCP 2.3 |
| Input/Output Resolutions | Supports VESA and SMPTE resolutions up to 4K@60Hz (4:4:4), including 3840×2160@60Hz, 4096×2160@50Hz, 4K@30Hz, 3840×1080@60Hz, 3440×1440@60Hz, 2560×1600@60Hz, 2560×1440@60Hz, 2560×1440@50Hz, 1080P@120Hz, 1080P@100Hz, 1080P@75Hz, 1080P@60Hz, 720P@60Hz |
| Maximum Data Rate | 18Gbps |
| Maximum Pixel Clock | 600MHz |
| Supported Standards | DCI, RGB |
| Audio Formats | HDMI: Supports multichannel audio up to PCM 7.1, including PCM 2.0/5.1/7.1ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS-HD Master Audio and DTS:X S/PDIF: PCM 2.0ch, Dolby Digital, DTS 5.1 |
| Transmission Distance | Cat 6/6A/7: 70m/230ft – 1080P@60Hz, 4K@60Hz HDMI : Input/Output: 15m/49ft – 1080p@60Hz Input/Output: 10m/33ft – 4K@60Hz Input: 10m/33ft – 4K@30Hz Output: 15m/49ft –4K@30Hz |
| Power Supply | DC 12V/1A, PoC |
| Power Consumption (Max) | 4.2W (per pair, via PoC) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 10% to 90%, non-condensing |
| ESD Protection | Human-body Model: ±8kV (Air-gap discharge) / ±4kV (Contact discharge) |
| Height x Width x Depth | 15mm / 0.59in x 63mm / 2.48in x 80mm / 3.15in |
| Weight | 0.29lb (0.13kg) per unit |
| Safety and Emission | CE, FCC, RoHS, RCM, EAC, UKCA |
