The EX-40-H2-ARC is a 4K60 4:4:4 HDBaseT 2.0 extender designed for residential applications that demand audio return flexibility. Featuring ARC and S/PDIF pathways from RX to TX and analog audio breakout from the HDMI input, this unit is the perfect fit for installations involving modern TVs and legacy audio systems.
HDMI Extender
WyreStorm EX-40-H2-ARC — 40m 4K HDBaseT Extender with ARC and Audio Breakout
The EX-40-H2-ARC is a 4K60 4:4:4 HDBaseT 2.0 extender designed for residential applications that demand audio return flexibility. Featuring ARC and S/PDIF pathways from RX to TX and analog audio breakout from the HDMI input, this unit is the perfect fit for installations involving modern TVs and legacy audio systems.
| Marka | WyreStorm |
|---|---|
| Model | EX-40-H2-ARC |
| Inputs | 1x HDMI (TX), 1x HDBaseT (RX) |
| Outputs | 1x HDMI (RX), 1x HDBaseT (TX), 1x Toslink, 1x Analog 3-pin Phoenix |
| End to End Latency | <1ms |
| Resolutions Supported | 800×600 , 1024×768 , 1280×768 , 1280×800 , 1280×960 , 1280×1024 , 1360×768 , 1366×768 , 1440×900 , 1600×900 , 1 600×1200 , 1680×1050 , 1920×1080 , 1920×1200 , 3840×2160 , 4096×2160 |
| Input Signal Type | HDMI with HDCP 2.2 |
| Maximum Pixel Clock | 600 MHz |
| Maximum Data Rate | 18Gbps |
| Video Resolutions (Max) | Up to 4096×2160 @ 60Hz 4:4:4 |
| Audio Formats Supported | HDMI: PCM 2.0/5.1/7.1, Dolby TrueHD, Atmos, DTS:X S/PDIF and ARC: PCM 2.0, Dolby Digital, DTS 5.1 |
| Transmission Distance | Cat 5e/6: 35m/115ft 4K@60Hz 4:4:4 60m/197ft 1080P@60Hz Cat 6a/7: 40m/131ft 4K@60Hz 4:4:4 70m/197ft 1080P@60Hz HDMI: Input/Output: 15m/49ft 1080p@60Hz Input/Output: 10m/33ft 4K@30Hz 4:4:4 Input/Output: 5m/16ft 4K@60Hz 4:4:4 |
| HDMI | HDCP 2.2, EDID, CEC (transparent on ARC) |
| RS-232 | Bi-directional, 3-pin Phoenix |
| IR | Bi-directional, 3.5mm TRS |
| Power Supply | DC 12V/3A |
| Max Power Consumption | Receiver is powered by transmitter: 18.72W Transmitter is powered by receiver: 18.96W Transmitter and receiver are powered separately: Transmitter: 8.4W Receiver: 6.6W |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 10% to 90%, non-condensing |
