WyreStorm EX-70-H2 — 4K HDBaseT Extender – High-Quality Video and Audio Transmission
4K HDBaseT Extender for seamless video and audio transmission over long distances. Ideal for home theater and commercial setups. Enhance your AV experience.
| Marka | WyreStorm |
|---|---|
| Model | EX-70-H2 |
| Inputs | TRANSMITTER 1x HDMI: 19-pin type A RECEIVER 1x HDBaseT 8-pin RJ-45 female |
| Outputs | 1x HDBT: 8-pin RJ-45 Female 1x HDMI: 19-pin type A |
| Output Video Encoding | HDBaseT™ Class A |
| Encoding Data Rate | 10.2Gbps |
| End to End Latency | 10μs (microseconds) |
| Audio Formats | 2ch PCM, Multichannel up to DTS-X and Dolby Atmos |
| Video Resolutions (max) | 1920x1080p @60Hz 16bit 3840x2160p @60Hz 10bit 4:2:0 HDR 4096x2160p @60Hz 8bit 4:4:4 |
| Supported Standards | DCI, RGB, Dolby Vision @ 30Hz, HLG, HDR-10 |
| Maximum Pixel Clock | HDMI: 600MHz, HDBaseT: 297MHz |
| HDMI | HDMI, HDCP 2.2, EDID, DVI/D supported with adapter (not included) |
| HDBaseT | HDMI, HDCP 2.2, EDID, 2-way PoH, Bidirectional IR, and RS-232 |
| CEC | CEC Pass-through – Requires CEC compatibility between source and display |
| IR | 1x IR TX: 3.5mm (1/8in) TS Mono 1x IR RX: 3.5mm (1/8in) TRS Stereo |
| RS-232 | 1x RS-232: 3-pin Terminal Block |
| Power Supply | 18V DC 1A |
| PoH | IEEE 802.3af 48V 15.4W Max, 2-way |
| Max Power Consumption | 4.68W |
| Ethernet | 1x Ethernet: 8-pin RJ-45 Female |
