WyreStorm SW-120-TX3-US — Synergy 2-Input 4K60Hz HDBaseT 3.0 In-Wall Transmitter
WyreStorm SW-120-TX3-US — Synergy 2-Input 4K60Hz HDBaseT 3.0 In-Wall Transmitter - Görsel 2
,

WyreStorm SW-120-TX3-US — Synergy 2-Input 4K60Hz HDBaseT 3.0 In-Wall Transmitter

Teklif Al

2 inputs and powerful HDBaseT 3.0 transmission result is this powerful switching transmitter, perfect for higher education classroom/hall and corporate environments. Automatic or manual switching of HDMI or USB-C and CEC power triggering via HDBaseT means a simple user experience when it matters most. Further functionality allows USB devices to be routed back to the source via USB host (or nativel

Stok kodu: SW-120-TX3-US Kategoriler: ,

2 inputs and powerful HDBaseT 3.0 transmission result is this powerful switching transmitter, perfect for higher education classroom/hall and corporate environments. Automatic or manual switching of HDMI or USB-C and CEC power triggering via HDBaseT means a simple user experience when it matters most. Further functionality allows USB devices to be routed back to the source via USB host (or natively via USB-C) and charging for the connected USB-C device.

Marka

WyreStorm
Model

SW-120-TX3-US
Inputs

1x HDMI: 19-pin Type A Female 1x USB-C (USB Alt Mode/Host) 1x RS-232: 3-pin Phoenix (Shared; API Control) 1x Line-In 3.5mm (1/8in) TRS Stereo 1x Type B host
Outputs

1 x HDBT: 8-pin RJ45 1x RS-232: 3-pin Phoenix (Shared; Passthrough)
Max Pixel Clock

600MHz
Video Resolution (Max)

1920x1080p @60Hz 12bit 3840×2160 @60Hz 4:4:4 8bit 5120×2160 @30Hz 5120×2160 @60Hz 4:2:0
Supported Standards

DCI, RGB, HDR10, Dolby Vision, HLG, BT.2020, BT.2100
Audio Formats

1x Audio In: 3.5mm (1/8in) TRS Stereo 2ch audio over HDBaseT, 1-way to RX
HDMI

HDMI, HDCP 2.3, EDID, CEC Pass-through
HDBaseT

HDMI, USB, HDCP 2.3, EDID, 2-way PoH, Bidirectional RS-232, CEC
USB

1x Type B (Host), Maximum data throughput: 300Mbps
RS-232

1x RS-232: 3-pin Phoenix
Power Supply

20V DC 6A (Sold separately)
Max Power Consumption

6.61W
