Powerful, next generation HDBaseT receiver compatible with WyreStorm’s presentation switcher platform, perfect for corporate meeting and classroom environments. Automatically switches between a remote source sent over HDBaseT and 2 local HDMI sources, all with USB device extension. CEC triggering and 3rd party device relays further contribute to a superior and autonomous presentation experience.
Presentation and Conferencing, Presentation Switcher
WyreStorm SW-515-RX — 4K HDBaseT Receiver with USB & Local Inputs
Powerful, next generation HDBaseT receiver compatible with WyreStorm’s presentation switcher platform, perfect for corporate meeting and classroom environments. Automatically switches between a remote source sent over HDBaseT and 2 local HDMI sources, all with USB device extension. CEC triggering and 3rd party device relays further contribute to a superior and autonomous presentation experience.
| Marka | WyreStorm |
|---|---|
| Model | SW-515-RX |
| Inputs | 2x HDMI In: 19-pin type A 1x HDBT In: 8-pin RJ-45 Female |
| Outputs | 1x HDMI Out: 19-pin type A 1x Audio Out: 3-pin Phoenix 1x Line Out: 3.5mm (1/8in) TRS Stereo |
| Video Encoding | HDBaseT™ Class C |
| Encoding Data Rate | 9.2Gbps |
| End to End Latency | 10μs (micro seconds) |
| Audio Formats | 2ch Analog/PCM, Multichannel: LPCM |
| Video Resolution (Max) | 1920x1080p @60Hz 8bit 1920x1200p @60Hz 8bit 3840x2160p @30Hz 8bit 4:4:4 4096x2160p @60Hz 8bit 4:2:0 |
| Supported Standards | DCI, RGB |
| Maximum Pixel Clock | 297MHz |
| HDMI | HDMI, HDCP 2.2, EDID, DVI/D supported with adapter (not included) |
| HDBaseT | HDMI, HDCP 2.2, EDID, CEC, 2ch audio, USB |
| RS-232 | 1x RS-232 (Control): 3-pin Phoenix, 1x RS-232 (Passthrough): 3-pin Phoenix |
| Ethernet | 2x 8-pin RJ-45 female, Bidirectional over HDBaseT™ |
| IR | 1x IR TX: 3.5mm (1/8in) TS Mono |
| Relays | 1x Screen UP: 3-pin Phoenix, 1x Screen DWN: 3-pin Phoenix |
| USB | 2x USB Host: USB-B, 3x USB Device: USB-A |
| Power Supply | 12V DC 2A |
| Max Power Consumption | 16.25W |
