WyreStorm SW-620-TX-W — Wireless Conferencing Solutions for Seamless Communication
WyreStorm SW-620-TX-W — Wireless Conferencing Solutions for Seamless Communication - Görsel 2
,

WyreStorm SW-620-TX-W — Wireless Conferencing Solutions for Seamless Communication

Teklif Al

Wireless Conferencing offers hassle-free, high-quality meetings with cutting-edge technology for effective communication and collaboration.

Stok kodu: SW-620-TX-W Kategoriler: ,

Wireless Conferencing offers hassle-free, high-quality meetings with cutting-edge technology for effective communication and collaboration.

Marka

WyreStorm
Model

SW-620-TX-W
Inputs

1x HDMI: 19-pin type A, up to 4K@30Hz 4:4:4 8bit 1x USB-C, Video input with MST, up to 2x 4K@30Hz Wireless Video from APO-DG2, APO-DG2-PRO (1080@60Hz, 2160@30Hz), Airplay or Miracast source (1080@60Hz)
Outputs

2x HDMI: 19-pin type A, Output 1 – 4K@60Hz 4:4:4 8bit, Output 2 – 4K@30Hz 4:4:4 8bit, 1x Analog Audio Output (5-pin Phoenix Male Connector)
Audio Formats

2ch PCM
Output Video Encoding

HDMI
Supported Standards

DCI, RGB
Maximum Pixel Clock

300MHz (600MHz on HDMI OUT1)
HDMI

HDMI CEC, HDCP 2.3, EDID
USB

3 x USB 3.0 Type A device ports, 5v 1000mA per port 1 x USB 3.0 Type B host port (assignable) 1 x USB 3.0 Type-C port
RS-232

1x 4-pin Phoenix (API control), Provides 12v power
LAN

2x 8-pin RJ-45 for API control (Telnet, TLS, HTTP/HTTPS for webUI)
Wireless

4x Wi-Fi Antennas, IEEE 802.11 a/b/g/n/ac, Dual-band 2.4 & 5GHz, WEP, TKIP, AES, WPA, WPA2 Max E.I.R.P. :16.38 dBm (43.45mW) WiFi Operation Frequency: 2.4G: 2412MHz~2462MHz 5G: 5180MHz~5240MHz 5.8G: 5745MHz~5805MHz Maximum Power: 14.89 dBm (E.I.R.P.) 16.38 dBm (E.I.R.P.) 10.81 dBm (E.I.R.P.)
Power Supply

20V 10A
Max Power Consumption

132W
