WyreStorm MX-0403-H3-MST — 4×3 Multi-Input Conference Room Switcher with Advanced USB-C Integration & HDBT 3.0 Output

Teklif Al

The MX-0403-H3-MST Conference Presentation Switcher builds on the success of the MX-0402-MST by adding an HDBaseT 3.0 output for signal extension of up to 100m. Designed to simplify and enhance your presentation experience, this 4×3 switcher integrates video, audio, USB, control, and Ethernet functionalities. With dual USB-C and dual HDMI inputs, automatic switching capabilities, and advanced USB

Stok kodu: MX-0403-H3-MST Kategoriler:

The MX-0403-H3-MST Conference Presentation Switcher builds on the success of the MX-0402-MST by adding an HDBaseT 3.0 output for signal extension of up to 100m. Designed to simplify and enhance your presentation experience, this 4×3 switcher integrates video, audio, USB, control, and Ethernet functionalities. With dual USB-C and dual HDMI inputs, automatic switching capabilities, and advanced USB 3.2 ports, the MX-0403-H3-MST ensures seamless connectivity and control for all your conference needs. Experience crystal-clear 4K video, high-speed data transfer, and efficient power delivery with this state-of-the-art presentation switcher.

Marka

WyreStorm
Model

MX-0403-H3-MST
Inputs

2x HDMI In: 19-pin Type A 2x USB-C
Outputs

2x HDMI Out: 19-pin Type A 1x Analog Audio Out (5-pin Phoenix Male Connector) 1x HDBaseT3 Out: RJ45
Output Video Encoding

18Gbps
Audio Formats

USB-C IN/HDMI IN/ HDMI OUT: Up to 7.1ch, including PCM 2.0/5.1/7.1ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS-HD Master Audio and DTS:X. Analog Audio de-embedding: 2ch Analog/PCM
Video Resolution (Max)

3840x2160p @60Hz 4:4:4 8bit 5120×2160 @30Hz 5120×2160 @60Hz 4:2:0
Data Rate

USB-C IN: 10Gbit/s (per lane). HDMI: 18Gbps. USB 3.2: 5Gbit/s.
HDR

All HDR formats, including HDR 10, HLG, HDR 10+ and Dolby Vision
Supported Standards

DCI, RGB
Maximum Pixel Clock

600MHz
Power Supply

20V
Max Power Consumption

Up to 200W
